5mm Thickness 4h-N 4H-SEMI SIC Silicon Carbide Wafer For Epitaxial
Silicon carbide (SiC), also known as carborundum, is a semiconductor containing silicon and carbon with chemical formula SiC. SiC is used in semiconductor electronics devices that operate at high temperatures or high voltages, or both.SiC is also one of the important LED components, it is a popular substrate for growing GaN devices, and it also serves as a heat spreader in high-power LEDs.
Customzied size/2inch/3inch/4inch/6inch 6H-N/4H-SEMI/ 4H-N SIC ingots/High purity 4H-N 4inch 6inch dia 150mm silicon carbide single
sic wafer 4Inch prime research dummy Grade 4H-N/SEMI standard size
About Silicon Carbide (SiC)Crystal
Silicon carbide (SiC), also known as carborundum, is a semiconductor containing silicon and carbon with chemical formula SiC. SiC is used in semiconductor electronics devices that operate at high temperatures or high voltages, or both.SiC is also one of the important LED components, it is a popular substrate for growing GaN devices, and it also serves as a heat spreader in high-power LEDs.
THE DATA SHEET OF 4″ SIC WAFER
Property
4H-SiC, Single Crystal
6H-SiC, Single Crystal
Lattice Parameters
a=3.076 Å c=10.053 Å
a=3.073 Å c=15.117 Å
Stacking Sequence
ABCB
ABCACB
Mohs Hardness
≈9.2
≈9.2
Density
3.21 g/cm3
3.21 g/cm3
Therm. Expansion Coefficient
4-5×10-6/K
4-5×10-6/K
Refraction Index @750nm
no = 2.61 ne = 2.66
no = 2.60 ne = 2.65
Dielectric Constant
c~9.66
c~9.66
Thermal Conductivity (N-type, 0.02 ohm.cm)
a~4.2 W/cm·K@298K c~3.7 W/cm·K@298K
Thermal Conductivity (Semi-insulating)
a~4.9 W/cm·K@298K c~3.9 W/cm·K@298K
a~4.6 W/cm·K@298K c~3.2 W/cm·K@298K
Band-gap
3.23 eV
3.02 eV
Break-Down Electrical Field
3-5×106V/cm
3-5×106V/cm
Saturation Drift Velocity
2.0×105m/s
2.0×105m/s
Are you a factory?
Yes, we are a professional manufacturer of optical components, we have more than 8years experience in wafers and optical lens process.
What is the MOQ of your products??
No MOQ for customer if our product is in stock, or 1-10pcs.
How can I get sample from you?
Just send us your requirements, then we will sendsamples accordingly.
How many days will samples be finished? How about mass products?
Generally, we need 1~2weeks to finish the sample production. As for the mass products, it depends on your order quantity.
What’s the delivery time?
(1)For inventory: the delivery time is 1-3 working days. (2) For customized products: the delivery time is 7 to 25 working days. According to the quantity.
How do you control the quality?
More than four times quality inspect during production process,we can provide the Quality test report.
Can I custom the products based on my requirement??
Yes, we can custom the material, specifications and optical coating for youroptical components as your requirement.
Frequently asked questions
What information should I provide for a custom SiC wafer?
Provide the polytype, diameter, thickness, orientation, conductivity or doping, surface finish, quantity and application. Feasibility and acceptance criteria should be confirmed for the order.
Can you customize the products based on my requirement?
Yes. The material, specifications and optical coating can be customized for optical components according to the customer requirement.
